Event Verify Server Configuration

The basic guide for EventVerify app server configuration.

Setting up server with Django

Introduction

This guide provides step-by-step instructions to set up a Django-based server for serving ticket data securely, using different authentication methods and formats. Choosing the right method depends on your project's requirements. Here's an overview to help you decide:

CSV vs. JSON

- **CSV**: Ideal for projects where data is exported for offline analysis or integration with external systems (e.g., spreadsheets or accounting software).
- **JSON**: Best suited for real-time applications or APIs that integrate with modern web or mobile apps. JSON is lightweight, structured, and easily parsed by applications.

Authentication Methods

1. **Bearer Token Authentication**
   - **Pros**: Simple, effective for stateless APIs, and widely used in RESTful services.
   - **Use Case**: Suitable for machine-to-machine communication or scenarios where the client can securely store the token (e.g., server-side applications).
   - **Setup Chapter**: CSV with Bearer Token Authentication or JSON with Bearer Token Authentication.

2. **Username and Password Authentication**
   - **Pros**: More familiar to users and allows human-readable credentials. Easy to integrate into existing user authentication systems.
   - **Use Case**: Ideal for applications requiring user authentication, such as admin dashboards or tools managed by multiple team members.
   - **Setup Chapter**: CSV with Username and Password Authentication or JSON with Username and Password Authentication.

When to Use?

- **CSV with Bearer Token Authentication**: Use for exporting secure, token-protected CSV files for system integrations or reporting tools.
- **CSV with Username and Password Authentication**: Ideal for admin tools where users log in with credentials to download CSV data.
- **JSON with Bearer Token Authentication**: Use for building stateless, token-secured APIs that serve structured ticket data to applications.
- **JSON with Username and Password Authentication**: Best for scenarios requiring authenticated access to structured data, often used in admin or reporting applications.

This guide provides standalone chapters for each setup, so you can jump directly to the section that matches your needs.


Introduction

CSV vs. JSON

Authentication Methods

When to Use?

Guide to Setting Up a CSV File Server with Auth Token

  1. Prerequisites
  1. Configure the models.py
  1. Add CSV Export Logic
  1. Configure URLs
  1. Test Your Setup

Guide to Setting Up a CSV File Server with Username and Password Authentication

  1. Prerequisites
  1. Configure the Models
  1. Add Basic Authentication Logic
  1. Create the CSV Export View
  1. Configure URLs
  1. Test the Setup

Guide to Setting Up a JSON Server with Bearer Token Authentication

  1. Prerequisites
  1. Configure the Models
  1. Add Bearer Token Authentication Logic
  1. Create the JSON Export View
  1. Configure URLs
  1. Test the Setup

Guide to Setting Up a JSON Server with Username and Password Authentication

  1. Prerequisites
  1. Configure the Models
  1. Add Basic Authentication Logic
  1. Create the JSON Export View

Configure URLs

Test the Setup



Guide to Setting Up a CSV File Server with Auth Token

1.  Prerequisites

Before starting, ensure you have the following:
1. Python 3.x installed on your system.
2. A fresh Django project. If you don't have one, run:

django-admin startproject ticket_server
cd ticket_server
python manage.py startapp tickets

3. Add the `tickets` app to your Django project:
   - Open `settings.py` in the `ticket_server` folder.
   - Add `'tickets'` to the `INSTALLED_APPS` list.
4. Install required libraries:

pip install django phonenumbers

2.  Configure the models.py

1. Navigate to the `tickets` app folder and open `models.py`.

2. Add the following code to define the `GlobalConfig` and `Ticket` models:

from django.db import models
import uuid

class GlobalConfig(models.Model):
    name = models.CharField(max_length=120, default="default")
    auth_code = models.CharField(
        max_length=120,
        default="3fK8#Tg7lQp45aFz!nXw9YrMv2Dc%hJ0VrL6oK7aBnC5jXqRmSaW8tYpL3sN1vB"
    )

    def __str__(self):
        return f"{self.name}"

def generate_ticket_id():
    return str(uuid.uuid4())

class Ticket(models.Model):
    new_idd = models.UUIDField(primary_key=True, default=generate_ticket_id, editable=False)
    ticket_id = models.CharField(max_length=255)
    times_scanned = models.IntegerField(default=0)
    description = models.TextField(blank=True, null=True)

    def __str__(self):
        return self.ticket_id

3. Run migrations to create the database tables:

python manage.py makemigrations
python manage.py migrate

3.  Add CSV Export Logic

1. Open `views.py` in the `tickets` app folder and add the following imports and helper functions:

from django.http import HttpResponse
from .models import Ticket, GlobalConfig

# Helper function to get the first alphabetical GlobalConfig
def get_global_config():
    return GlobalConfig.objects.order_by('name').first()

# Verify Bearer Token Authentication
def verify_bearer_token(request):
    config = get_global_config()
    auth_header = request.headers.get('Authorization', '')
    token_type, _, token = auth_header.partition(' ')
    return token_type == 'Bearer' and token == config.auth_code

2. Add the CSV generation and token-protected view:

import csv
from django.views.decorators.http import require_http_methods

def show_csv(request):
    response = HttpResponse(content_type='text/csv')
    response['Content-Disposition'] = 'attachment; filename="tickets.csv"'

    writer = csv.writer(response)
    writer.writerow(['Ticket ID', 'Scanned', 'Description'])

    for ticket in Ticket.objects.all():
        writer.writerow([ticket.ticket_id, ticket.times_scanned, ticket.description])

    return response

@require_http_methods(["GET"])
def bearer_csv(request):
    if not verify_bearer_token(request):
        return HttpResponse("Unauthorized", status=401)
    return show_csv(request)

4.  Configure URLs

1. Create a `urls.py` file in the `tickets` app folder (if it doesn’t exist) and add the following code:

from django.urls import path
from .views import bearer_csv

urlpatterns = [
    path('csv/', bearer_csv, name='bearer_csv'),
]

2. Link the app’s `urls.py` to the main project:

Open the `urls.py` file in the `ticket_server` folder.

from django.urls import include, path

urlpatterns = [
    path('tickets/', include('tickets.urls')),
]

5.  Test Your Setup

1. Run the server:

python manage.py runserver

2. Create a `GlobalConfig` entry in the Django admin panel:
   - Run:

python manage.py createsuperuser

   - Log in at `http://127.0.0.1:8000/admin/`.
   - Add a new `GlobalConfig` object with your desired `auth_code`.

3. Add some tickets to test the functionality:
   - Either through the admin panel or directly in the shell:

python manage.py shell



from tickets.models import Ticket
Ticket.objects.create(ticket_id="123456", description="Test ticket”)

4. Test the token-protected endpoint:
   - Use `curl` or a tool like Postman to make a request:

curl -H "Authorization: Bearer <your_auth_code>" http://127.0.0.1:8000/tickets/csv/


Guide to Setting Up a CSV File Server with Username and Password Authentication

1.  Prerequisites

Before starting, ensure you have the following:
1. Python 3.x installed on your system.
2. A fresh Django project. If you don't have one, run:

django-admin startproject ticket_server
cd ticket_server
python manage.py startapp tickets

3. Add the `tickets` app to your Django project:
   - Open `settings.py` in the `ticket_server` folder.
   - Add `'tickets'` to the `INSTALLED_APPS` list.
4. Install required libraries:

pip install django phonenumbers

2.  Configure the Models

1. Navigate to the `tickets` app folder and open `models.py`.

2. Add the following code to define the `GlobalConfig` and `Ticket` models:

from django.db import models
import uuid

class GlobalConfig(models.Model):
    name = models.CharField(max_length=120, default="default")
    username = models.CharField(max_length=120, default="example_user")
    password = models.CharField(max_length=120, default="example_password")

    def __str__(self):
        return f"{self.name}"

def generate_ticket_id():
    return str(uuid.uuid4())

class Ticket(models.Model):
    new_idd = models.UUIDField(primary_key=True, default=generate_ticket_id, editable=False)
    ticket_id = models.CharField(max_length=255)
    times_scanned = models.IntegerField(default=0)
    description = models.TextField(blank=True, null=True)

    def __str__(self):
        return self.ticket_id

3. Apply the migrations:

python manage.py makemigrations
python manage.py migrate

3.  Add Basic Authentication Logic

1. Open `views.py` in the `tickets` app folder and add the following imports and helper functions:

import base64
from django.http import HttpResponse
from .models import Ticket, GlobalConfig

# Helper function to get the first alphabetical GlobalConfig
def get_global_config():
    return GlobalConfig.objects.order_by('name').first()

# Verify Basic Authentication
def verify_basic_auth(request):
    config = get_global_config()
    auth_header = request.headers.get('Authorization', '')
    token_type, _, encoded_credentials = auth_header.partition(' ')

    if token_type != 'Basic' or not encoded_credentials:
        return False

    decoded_credentials = base64.b64decode(encoded_credentials).decode()
    username, _, password = decoded_credentials.partition(':')
    return username == config.username and password == config.password

4.  Create the CSV Export View

1. Add a function to generate and serve the CSV file:

import csv
from django.views.decorators.http import require_http_methods

def show_csv(request):
    response = HttpResponse(content_type='text/csv')
    response['Content-Disposition'] = 'attachment; filename="tickets.csv"'

    writer = csv.writer(response)
    writer.writerow(['Ticket ID', 'Scanned', 'Description'])

    for ticket in Ticket.objects.all():
        writer.writerow([ticket.ticket_id, ticket.times_scanned, ticket.description])

    return response

2. Add the Basic Authentication-protected view:

@require_http_methods(["GET"])
def basic_csv(request):
    if not verify_basic_auth(request):
        return HttpResponse("Unauthorized", status=401)
    return show_csv(request)

5.  Configure URLs

1. Create a `urls.py` file in the `tickets` app folder (if it doesn’t exist) and add the following code:

from django.urls import path
from .views import basic_csv

urlpatterns = [
    path('csv/basic/', basic_csv, name='basic_csv'),
]

2. Link the app’s `urls.py` to the main project:

Open the `urls.py` file in the `ticket_server` folder.

from django.urls import include, path

urlpatterns = [
    path('tickets/', include('tickets.urls')),
]

6.  Test the Setup

  1. Run the server:
python manage.py runserver
  1. Create a `GlobalConfig` entry in the Django admin panel:
       - Run:
python manage.py createsuperuser

   - Log in at `http://127.0.0.1:8000/admin/`.
   - Add a new `GlobalConfig` object with the desired username and password:
     - `username`: `test_user`
     - `password`: `test_password`
3. Add some test tickets:

python manage.py shell



from tickets.models import Ticket

Ticket.objects.create(ticket_id="123456", description="Test ticket”)

4. Test the Basic Authentication-protected endpoint:

curl -u test_user:test_password http://127.0.0.1:8000/tickets/csv/basic/


Guide to Setting Up a JSON Server with Bearer Token Authentication

1.  Prerequisites

Before starting, ensure you have the following:
1. Python 3.x installed on your system.
2. A fresh Django project. If you don't have one, run:

django-admin startproject ticket_server
cd ticket_server
python manage.py startapp tickets

3. Add the `tickets` app to your Django project:
   - Open `settings.py` in the `ticket_server` folder.
   - Add `'tickets'` to the `INSTALLED_APPS` list.
4. Install required libraries:

pip install django phonenumbers

2.  Configure the Models

1. Navigate to the `tickets` app folder and open `models.py`.

2. Add the following code to define the `GlobalConfig` and `Ticket` models:

from django.db import models
import uuid

class GlobalConfig(models.Model):
    name = models.CharField(max_length=120, default="default")
    auth_code = models.CharField(max_length=120, default="example_token")

    def __str__(self):
        return f"{self.name}"

def generate_ticket_id():
    return str(uuid.uuid4())

class Ticket(models.Model):
    new_idd = models.UUIDField(primary_key=True, default=generate_ticket_id, editable=False)
    ticket_id = models.CharField(max_length=255)
    times_scanned = models.IntegerField(default=0)
    description = models.TextField(blank=True, null=True)

    def __str__(self):
        return self.ticket_id

3. Apply the migrations:

python manage.py makemigrations
python manage.py migrate

3.  Add Bearer Token Authentication Logic

1. Open `views.py` in the `tickets` app folder and add the following imports and helper functions:

from django.http import JsonResponse
from .models import Ticket, GlobalConfig

# Helper function to get the first alphabetical GlobalConfig
def get_global_config():
    return GlobalConfig.objects.order_by('name').first()

# Verify Bearer Token Authentication
def verify_bearer_token(request):
    config = get_global_config()
    auth_header = request.headers.get('Authorization', '')
    token_type, _, token = auth_header.partition(' ')
    return token_type == 'Bearer' and token == config.auth_code

4.  Create the JSON Export View

1. Add a view to generate and serve JSON data:

from django.views.decorators.http import require_http_methods

@require_http_methods(["GET"])
def bearer_json(request):
    if not verify_bearer_token(request):
        return HttpResponse("Unauthorized", status=401)

    tickets = Ticket.objects.values('ticket_id', 'times_scanned', 'description')
    return JsonResponse(list(tickets), safe=False)

5.  Configure URLs

1. Create a `urls.py` file in the `tickets` app folder (if it doesn’t exist) and add the following code:

from django.urls import path
from .views import bearer_json

urlpatterns = [
    path('json/bearer/', bearer_json, name='bearer_json'),
]

2. Link the app’s `urls.py` to the main project:

Open the `urls.py` file in the `ticket_server` folder.

from django.urls import include, path

urlpatterns = [
    path('tickets/', include('tickets.urls')),
]

6.  Test the Setup

  1. Run the server:
python manage.py runserver
  1. Create a `GlobalConfig` entry in the Django admin panel:
       - Run:
python manage.py createsuperuser
  1.    - Log in at `http://127.0.0.1:8000/admin/`.
       - Add a new `GlobalConfig` object with the desired `auth_code`:
         - `auth_code`: `example_token`
  2. Add some test tickets:
python manage.py shell



from tickets.models import Ticket
Ticket.objects.create(ticket_id="123456", description="Test ticket”)
  1. Test the Bearer Token-protected endpoint:
curl -H "Authorization: Bearer example_token" http://127.0.0.1:8000/tickets/json/bearer/


Guide to Setting Up a JSON Server with Username and Password Authentication

1.  Prerequisites

Before starting, ensure you have the following:
1. Python 3.x installed on your system.
2. A fresh Django project. If you don't have one, run:

django-admin startproject ticket_server
cd ticket_server
python manage.py startapp tickets

3. Add the `tickets` app to your Django project:
   - Open `settings.py` in the `ticket_server` folder.
   - Add `'tickets'` to the `INSTALLED_APPS` list.
4. Install required libraries:

pip install django phonenumbers

2.  Configure the Models

1. Navigate to the `tickets` app folder and open `models.py`.

2. Add the following code to define the `GlobalConfig` and `Ticket` models:


from django.db import models
import uuid

class GlobalConfig(models.Model):
    name = models.CharField(max_length=120, default="default")
    auth_code = models.CharField(max_length=120, default="example_token")

    def __str__(self):
        return f"{self.name}"

def generate_ticket_id():
    return str(uuid.uuid4())

class Ticket(models.Model):
    new_idd = models.UUIDField(primary_key=True, default=generate_ticket_id, editable=False)
    ticket_id = models.CharField(max_length=255)
    times_scanned = models.IntegerField(default=0)
    description = models.TextField(blank=True, null=True)

    def __str__(self):
        return self.ticket_id


3. Apply the migrations:

python manage.py makemigrations
python manage.py migrate

3.  Add Basic Authentication Logic

1. Open `views.py` in the `tickets` app folder and add the following imports and helper functions:


import base64
from django.http import JsonResponse
from .models import Ticket, GlobalConfig

# Helper function to get the first alphabetical GlobalConfig
def get_global_config():
    return GlobalConfig.objects.order_by('name').first()

# Verify Basic Authentication
def verify_basic_auth(request):
    config = get_global_config()
    auth_header = request.headers.get('Authorization', '')
    token_type, _, encoded_credentials = auth_header.partition(' ')

    if token_type != 'Basic' or not encoded_credentials:
        return False

    decoded_credentials = base64.b64decode(encoded_credentials).decode()
    username, _, password = decoded_credentials.partition(':')
    return username == config.username and password == config.password


4.  Create the JSON Export View

1. Add a view to generate and serve JSON data:


from django.views.decorators.http import require_http_methods

@require_http_methods(["GET"])
def basic_json(request):
    if not verify_basic_auth(request):
        return HttpResponse("Unauthorized", status=401)

    tickets = Ticket.objects.values('ticket_id', 'times_scanned', 'description')
    return JsonResponse(list(tickets), safe=False)


Configure URLs

1. Create a `urls.py` file in the `tickets` app folder (if it doesn’t exist) and add the following code:

from django.urls import path
from .views import basic_json

urlpatterns = [
    path('json/basic/', basic_json, name='basic_json'),
]

2. Link the app’s `urls.py` to the main project:
Open the `urls.py` file in the `ticket_server` folder.

from django.urls import include, path

urlpatterns = [
    path('tickets/', include('tickets.urls')),
]

Test the Setup

  1. Run the server:
python manage.py runserver
  1. Create a `GlobalConfig` entry in the Django admin panel:
       - Run:
python manage.py createsuperuser
  1.    - Log in at `http://127.0.0.1:8000/admin/`.
       - Add a new `GlobalConfig` object with the desired username and password:
         - `username`: `test_user`
         - `password`: `test_password`
  2. Add some test tickets:
python manage.py shell



from tickets.models import Ticket
Ticket.objects.create(ticket_id="123456", description="Test ticket”)
  1. Test the Basic Authentication-protected endpoint:
curl -u test_user:test_password http://127.0.0.1:8000/tickets/json/basic/

You have successfully set up a JSON server protected by Basic Authentication. Users must provide valid credentials in the request header to access the data.




(Mobile Apps)

Duszekjk Jacek Kałużny

Cookies
This website uses cookies because it is a website
